Schneider Electric IC65N2PC20A + VIGI2P40A Combination Overview
1. IC65N2PC20A – 2-Pole 20 A Miniature Circuit Breaker (MCB)
| Parameter | Description |
|---|---|
| Model | IC65N2PC20A |
| Poles | 2P (two poles) |
| Rated Current | 20 A |
| Rated Voltage | 400 V AC (compliant with GB 10963.1 and EN 60898-1 standards) |
| Breaking Capacity | 6 kA (short-circuit current) |
| Tripping Curve | C-curve (suitable for inductive loads and general lighting) |
| Dimensions | Width 36 mm, fits standard 35 mm DIN rail |
| Installation | Direct snap-on to standard 35 mm DIN rail; terminals support cable or busbar connections |
| Indication | Red indicator window on the front shows fault status |
| Environmental Certification | Green Premium™ (REACH, RoHS compliant) |
Typical Applications
- Overload and short-circuit protection for lighting and power circuits
- 2-pole or 3-pole distribution branches within distribution boards/panels
- Industrial and commercial electrical systems requiring quick installation and easy maintenance
2. VIGI2P40A – 2-Pole 40 A Electronic Residual Current Device (RCD)
| Parameter | Description |
|---|---|
| Model | VIGI OSM 2P 40A (also referred to as VIGI2P40A) |
| Poles | 2P (two poles) |
| Rated Current | 40 A |
| Rated Residual Operating Current | 30 mA |
| Sensitivity Type | Type-A (sensitive to AC and pulsating DC residual currents) |
| Rated Operating Voltage | 230 V AC (suitable for 230–415 V systems) |
| Dimensions | Width 36 mm, compatible with 35 mm DIN rail |
| Installation | Snap-on DIN rail mounting; tunnel-type terminals (accept 1–25 mm² flexible or solid wires) |
| Environmental Certification | Green Premium™, compliant with REACH, RoHS, mercury-free requirements |
Typical Applications
- Residual current (earth leakage) protection in residential, commercial, and industrial electrical systems
- Used together with the iC65 MCB series to provide an MCB + RCD combined protection scheme (commonly used in “2-pole + RCD” distribution setups)
- Reliable detection of leakage currents for inductive or pulse-current loads
3. Advantages of the Combination
Complete Overload/Short-Circuit + Residual Current Protection
IC65N2PC20A provides overload and short-circuit protection, while VIGI2P40A handles residual current detection, forming a full MCB + RCD protection system.
Unified Dimensions & Easy Installation
Both units are 36 mm wide and can be installed side-by-side on the same DIN rail, saving space and simplifying wiring.
Environmentally Friendly
Both are certified under Schneider’s Green Premium™ program, meeting modern environmental and sustainability requirements.
High Compatibility
VIGI2P40A terminals are designed to be compatible with iC65 series busbars and screw terminals, allowing fast and convenient field wiring.
Summary
The combination of the IC65N2PC20A and VIGI2P40A is a standardized, eco-friendly, and easy-to-install protection solution offered by Schneider Electric for low-voltage distribution systems. It is suitable for residential, commercial, and industrial applications, providing reliable dual protection against overload/short-circuit faults and residual current leakage.
